microEnable 5 marathon – The Frame Grabber for Highest Expectations

The marathon frame grabbers are powerful image acquisition and preprocessing boards for important digital interfaces in machine vision. They dominate with their wide range of deployment options in all important industries and application areas. Their integrated FPGA features high parallel processing, low thermal power, deterministic latencies and long market availability. All frame grabbers are developed by our Mannheim, Germany office (formerly Silicon Software).

The frame grabbers are equipped with an extensive internal memory for lossless image transfer and include a powerful vision processor (Xilinx FPGA of the Kintex 7 series) plus two independently configurable GPIO connectors (front GPIO and onboard GPIO for expansion with add-on hardware), enabling the power supply for cameras via Camera Link (Power over Camera Link) and CoaXPress (Power over CoaXPress). The programmable version enables implementation of complex algorithms for real-time image processing.

For new technologies such as Deep Learning, a programmable frame grabber (Camera Link) with high computing power was specially developed in the form of the microEnable 5 marathon deepVCL, which handles bandwidths in excess of 200 Mbps thanks to a higher-performance FPGA and thus supports larger neural networks without delays. Data-reducing image preprocessing makes it possible to use smaller networks or FPGAs.

Your advantages at a glance

  • Fast installation and camera connection
  • Deployment of newest FPGA technology
  • Support of Camera Link, CoaXPress (CXP-6) and Camera Link HS interfaces
  • Integrated real-time image preprocessing, such as bayer filter, lookup tables and white balance
  • Easy setup of multi-camera systems and integration of diverse control devices
  • Support for different sensor types (monochrome, color, area and line scan sensors)

  • Multiple options for the control of incoming and outgoing signal data by diverse GPIOs
  • Interference-free data transfer even over longer cable lengths
  • Robust hardware design for demanding vision applications in industrial environments
  • Special deep learning frame grabber with high processing bandwidth
  • Attractive price/performance ratio

The marathon Frame Grabber – The industry frontrunner

Its true performance is revealed in intense use.

Discover microEnable 5 marathon

microEnable 5 marathon frame grabber

  • Intelligent image acquisition and programmable image processing frame grabber
  • PCI Express x4 (Gen2) technology
  • Image transfer technology DMA1800 with up to 1.8 Gbps data bandwidth
  • Image memory between 512 and 2048 MB DDR3-RAM
  • Signal communication and programming via onboard and front trigger
  • Synchronization of several frame grabbers by front and/or onboard GPIOs
  • Power supply for cameras via power-over technology (for Camera Link and CXP-6 interface)
Show Filter
Reset filters
Interface Acquisition Type Camera series No. of Ports Data Bandwidth (p.port; Total) Model Name Interface Acquisition Type Compatible Cameras Data Bandwidth (p.port; Total) No. of Ports Availability i
Frame grabber 4 6,25 Gbps; 25 Gbps microEnable 5 marathon ACX-QP CXP-6 Frame grabber
  • Third Party
6,25 Gbps; 25 Gbps 4
Frame grabber 2 6,25 Gbps; 12,5 Gbps microEnable 5 marathon ACX-DP CXP-6 Frame grabber
  • Third Party
6,25 Gbps; 12,5 Gbps 2
Frame grabber 1 6,25 Gbps; 6,25 Gbps microEnable 5 marathon ACX-SP CXP-6 Frame grabber
  • Third Party
6,25 Gbps; 6,25 Gbps 1
Frame grabber 4 6,25 Gbps; 25 Gbps microEnable 5 marathon VCX-QP CXP-6 Frame grabber
  • Third Party
6,25 Gbps; 25 Gbps 4
Frame grabber 2 6,8 Gbps; 6,8 Gbps (850 MB/s) microEnable 5 marathon ACL Camera Link Frame grabber
  • Basler beat
  • Basler ace
  • Basler racer
  • Third Party
6,8 Gbps; 6,8 Gbps (850 MB/s) 2
Frame grabber 2 6,8 Gbps; 6,8 Gbps (850 MB/s) microEnable 5 marathon VCL Camera Link Frame grabber
  • Basler beat
  • Basler ace
  • Basler racer
  • Third Party
6,8 Gbps; 6,8 Gbps (850 MB/s) 2
Frame grabber null microEnable 5 marathon VCLx Frame grabber
  • Basler beat
  • Basler ace
  • Basler racer
  • Third Party
Frame grabber 2 6,8 Gbps; 6,8 Gbps (850 MB/s) microEnable 5 marathon deepVCL Camera Link Frame grabber
  • Basler beat
  • Basler ace
  • Basler racer
  • Third Party
6,8 Gbps; 6,8 Gbps (850 MB/s) 2

Sorry, there are no results for the selected filters.

More Accessories
microDisplay X

microDisplay X

During the activation of frame grabbers, microDisplay X helps you test the entire system configuration, select and parameterize applets and perform camera settings.

  • Configure cameras (GenICam) and applets directly in the start window and save or access the configuration
  • Load multiple applets (one applet per board)
  • Enlarge DMA (Direct Memory Access) output window for a large-scale display of an individual DMA output
  • Optimized accuracy of the frame rate information (frames per second) during the acquisition
  • Easy setup of line scan camera systems with line profile and line histogram (provide information on individual pixel values and the distribution of a line)
  • Buffer assigned in applet but not used (if the image section transferred by the camera is too small) is displayed in red in the DMA output window
  • New log window to access general and camera discovery log information, grabber events and system status information at any time

More about microDisplay X
microDiagnostics

microDiagnostics

microDiagnostics makes it possible to flash a frame grabber with applets and perform various tests for a successful activation

  • Support with the speedy activation of the frame grabber
  • Test functions simplify an overview of the full system’s functionality
  • Simple camera change by selecting and flashing another applet

More about microDiagnostics
SDKs

SDKs

The Software Development Kit (SDK) is an easy way to integrate a frame grabber and camera into the customer’s application while using complex trigger settings, particularly the microEnable frame grabber function, to their full extent. A generic application programming interface (API) enables platform-independent work. Of course, the SDK also helps system builders develop their own C/C++/C# or Python applications.

  • Quick and easy integration of frame grabbers into your application and software environment
  • Flexible for the use of different programming languages (C++, C#, Python)
  • Reduced development times for projects

More about SDKs
Basler pylon Camera Software Suite

Basler pylon Camera Software Suite

With the pylon Camera Software Suite you can set up your boost camera and all its functions in a quick and effective way. It also helps you to integrate the camera into your software.

Basler pylon Camera Software Suite
VisualApplets 3

VisualApplets 3

VisualApplets enables access to the FPGA processors in the image processing hardware, such as frame grabbers, industrial cameras and image processing devices, to implement individual image processing applications.

  • Programming of the V-series frame grabbers and image processing hardware with special applications
  • Bandwidth control and FPGA resource assessment
  • Without expert skills or hardware programming
  • Reuse proprietary VHDL libraries in VisualApplets
  • Shorten project times, accelerate market availability

More about VisualApplets 3
VisualApplets Embedder

VisualApplets Embedder

Image processing devices become compatible with VisualApplets

  • Unlimited configuration of FPGA hardware with specific image processing applications
  • Promptly adjust image processing applications to customer and market requirements
  • Plan and implement complete product lines in a short time
  • Transfer developed image processing applications to different vision devices with minimal effort
  • Reduce the data volume with image pre-processing and alternatively apply inexpensive interfaces such as Gigabit Ethernet
  • End customers get the added value of programming the devices themselves in a specified framework
  • End customers receive smart devices that guarantee them the most flexibility and investment reliability

More about VisualApplets Embedder
VisualApplets Expert

VisualApplets Expert

Experienced users have the option of applying existing hardware code, debugging the design under runtime conditions and creating paths to parameters in hierarchical structures.

  • With the custom library, system builders apply their image processing modules programmed in VHDL or Verilog (VHDL libraries) in VisualApplets as generic operators, thus preserving their preparatory work.
  • The debugging library enables enhanced debugging to detect programming errors, deadlocks and bandwidth problems and to increase the design stability.
  • The parameters library offers users tools to change even those parameters that might be deeply embedded in the design’s hierarchical structures. The changes are automatically and consistently updated during the runtime.

More about VisualApplets Expert
VisualApplets Libraries

VisualApplets Libraries

VisualApplets libraries comprise multiple operator libraries which expand the operators’ scope with valuable image processing functions, such as those for segmentation, classification and compression.

  • Segmentation/classification: These operators are used to segment and define objects in images and assign characteristics to them.
  • Compression: The JPEG operator makes it possible to execute the JPEG image compression directly on the FPGA of the vision hardware to reduce image data.

More about VisualApplets Libraries
VisualApplets Protection

VisualApplets Protection

To prevent the use of proprietary applets on external frame grabbers and thus protect intellectual property from outside access, the applets and frame grabbers can each be securely encoded with a lock.

  • Applets and frame grabbers are each securely encoded with a lock.
  • Two protective mechanisms guarantee maximum security.

More about VisualApplets Protection
