microEnable 5 ironman – Frame Grabbers in the Upper Performance Segment

The ironman frame grabbers are among the most powerful image acquisition and preprocessing boards in machine vision in all major industrial and application areas. The integrated FPGA features high parallel processing, low thermal power, and deterministic latencies. All frame grabbers are developed by our Mannheim, Germany office (formerly Silicon Software).

The me5 ironman is a high performance frame grabber equipped with an extensive internal memory of 1 or 2 GB for lossless image transfer. It features a powerful vision processor (Xilinx FPGA of the Virtex 6 series) and has a wide range of deployment options via an onboard GPIO using add-on trigger hardware. The power supply of the cameras is ensured by their power over functionality feature (Power over Camera Link and Power over CoaXPress). The programmable version allows implementation of complex algorithms for real-time image processing.

Your advantages at a glance

  • Fast installation and camera connection
  • Deployment of powerful FPGA technology
  • Support of Camera Link and CoaXPress (CXP-6) interfaces
  • Extended image preprocessing, such as debayering and shading and fixed pattern noise correction
  • Easy setup of multi-camera systems

  • Setup and synchronization of several frame grabbers using add-on trigger boards
  • Support for different sensor types (monochrome, color, area and line scan sensors)
  • Interference-free data transfer even over longer cable lengths
  • Robust industrial use with high MBTF values

The ironman Frame Grabbers – Bar surpassed

In the most demanding applications, they rush far ahead.

Discover microEnable 5 ironman

microEnable 5 ironman frame grabber

  • High-performance frame grabber for intelligent image acquisition and preprocessing
  • Capability of programming own algorithms of image preprocessing (boards of the V-line)
  • PCI Express x8 (Gen2) technology
  • Image transfer technology DMA3600 with up to 3.6 Gbps data bandwidth
  • Onboard image acquisition memory of 1 or 2 GB DDR3 RAM
  • 34-pin trigger/IO interface (onboard)
  • Synchronization of several frame grabbers by onboard IO interface and additional add-on hardware
  • Power supply for cameras via power-over-technology (for Camera Link and CXP-6 interface)
Interface Acquisition Type Camera series No. of Ports Data Bandwidth (p.port; Total) Model Name Interface Acquisition Type Camera series Data Bandwidth (p.port; Total) No. of Ports Availability i
Frame grabber 2 6,8 Gbps; 6,8 Gbps (850 MB/s) microEnable 5 ironman VD8-PoCL Camera Link Frame grabber
  • Third Party
6,8 Gbps; 6,8 Gbps (850 MB/s) 2
Frame grabber 2 6,8 Gbps; 6,8 Gbps (850 MB/s) microEnable 5 ironman AD8-PoCL Camera Link Frame grabber
  • Third Party
6,8 Gbps; 6,8 Gbps (850 MB/s) 2
Frame grabber 4 6,25 Gbps; 25 Gbps microEnable 5 ironman VQ8-CXP6D CXP-6 Frame grabber
  • Third Party
6,25 Gbps; 25 Gbps 4
Frame grabber 4 6,25 Gbps; 25 Gbps microEnable 5 ironman AQ8-CXP6D CXP-6 Frame grabber
  • Third Party
6,25 Gbps; 25 Gbps 4

Sorry, there are no results for the selected filters.

More Accessories
microDisplay X

microDisplay X

During the activation of frame grabbers, microDisplay X helps you test the entire system configuration, select and parameterize applets and perform camera settings.

  • Configure cameras (GenICam) and applets directly in the start window and save or access the configuration
  • Load multiple applets (one applet per board)
  • Enlarge DMA (Direct Memory Access) output window for a large-scale display of an individual DMA output
  • Optimized accuracy of the frame rate information (frames per second) during the acquisition
  • Easy setup of line scan camera systems with line profile and line histogram (provide information on individual pixel values and the distribution of a line)
  • Buffer assigned in applet but not used (if the image section transferred by the camera is too small) is displayed in red in the DMA output window
  • New log window to access general and camera discovery log information, grabber events and system status information at any time

More about microDisplay X
microDiagnostics

microDiagnostics

microDiagnostics makes it possible to flash a frame grabber with applets and perform various tests for a successful activation

  • Support with the speedy activation of the frame grabber
  • Test functions simplify an overview of the full system’s functionality
  • Simple camera change by selecting and flashing another applet

More about microDiagnostics
SDKs

SDKs

The Software Development Kit (SDK) is an easy way to integrate a frame grabber and camera into the customer’s application while using complex trigger settings, particularly the microEnable frame grabber function, to their full extent. A generic application programming interface (API) enables platform-independent work. Of course, the SDK also helps system builders develop their own C/C++/C# or Python applications.

  • Quick and easy integration of frame grabbers into your application and software environment
  • Flexible for the use of different programming languages (C++, C#, Python)
  • Reduced development times for projects

More about SDKs
Basler pylon Camera Software Suite

Basler pylon Camera Software Suite

With the pylon Camera Software Suite you can set up your boost camera and all its functions in a quick and effective way. It also helps you to integrate the camera into your software.

Basler pylon Camera Software Suite
VisualApplets 3

VisualApplets 3

VisualApplets enables access to the FPGA processors in the image processing hardware, such as frame grabbers, industrial cameras and image processing devices, to implement individual image processing applications.

  • Programming of the V-series frame grabbers and image processing hardware with special applications
  • Bandwidth control and FPGA resource assessment
  • Without expert skills or hardware programming
  • Reuse proprietary VHDL libraries in VisualApplets
  • Shorten project times, accelerate market availability

More about VisualApplets 3
VisualApplets Embedder

VisualApplets Embedder

Image processing devices become compatible with VisualApplets

  • Unlimited configuration of FPGA hardware with specific image processing applications
  • Promptly adjust image processing applications to customer and market requirements
  • Plan and implement complete product lines in a short time
  • Transfer developed image processing applications to different vision devices with minimal effort
  • Reduce the data volume with image pre-processing and alternatively apply inexpensive interfaces such as Gigabit Ethernet
  • End customers get the added value of programming the devices themselves in a specified framework
  • End customers receive smart devices that guarantee them the most flexibility and investment reliability

More about VisualApplets Embedder
VisualApplets Expert

VisualApplets Expert

Experienced users have the option of applying existing hardware code, debugging the design under runtime conditions and creating paths to parameters in hierarchical structures.

  • With the custom library, system builders apply their image processing modules programmed in VHDL or Verilog (VHDL libraries) in VisualApplets as generic operators, thus preserving their preparatory work.
  • The debugging library enables enhanced debugging to detect programming errors, deadlocks and bandwidth problems and to increase the design stability.
  • The parameters library offers users tools to change even those parameters that might be deeply embedded in the design’s hierarchical structures. The changes are automatically and consistently updated during the runtime.

More about VisualApplets Expert
VisualApplets Libraries

VisualApplets Libraries

VisualApplets libraries comprise multiple operator libraries which expand the operators’ scope with valuable image processing functions, such as those for segmentation, classification and compression.

  • Segmentation/classification: These operators are used to segment and define objects in images and assign characteristics to them.
  • Compression: The JPEG operator makes it possible to execute the JPEG image compression directly on the FPGA of the vision hardware to reduce image data.

More about VisualApplets Libraries
VisualApplets Protection

VisualApplets Protection

To prevent the use of proprietary applets on external frame grabbers and thus protect intellectual property from outside access, the applets and frame grabbers can each be securely encoded with a lock.

  • Applets and frame grabbers are each securely encoded with a lock.
  • Two protective mechanisms guarantee maximum security.

More about VisualApplets Protection
Acquisition Card

Manuals

The manuals provide complete information on all aspects of usage - from installing frame grabbers and software to first acquisition checks to advanced image processing. Described are all frame grabber series and models available together with their hardware and software add-ons, their specific functionalities and all image processing options along with the graphical FPGA development environment VisualApplets.

Acquisition Card

Brochures

Basler product brochures provide an overview of the many benefits offered by Basler accessories. They describe technical characteristics and product features and offer detailed information about the technical specifications.

Acquisition Card

White Papers

Basler White Papers provide a comprehensive overview of the fundamental theory of industrial image processing. The authors are all experts in their respective fields and go into detail on relevant thematic points of interest to novices and experienced users alike.

Acquisition Card

Product Insights

Basler Product Insights highlight noteworthy information about the technical properties and features of various accessories. The Product Insights focus strongly on product-related topics, offering insights from the point of view of a Basler product manager.

Acquisition Card

Customer Stories

Basler Customer Stories describe a broad diversity of applications and potential uses for Basler frame grabbers on a variety of markets. They explain the requirements Basler’s customers had to face while designing their image processing system and how Basler frame frabbers successfully contributed to resolving the problem.

Acquisition Card
Basler boost

Basler boost

Basler’s camera series with CoaXPress 2.0 for high bandwidths and high resolutions

Trigger Boards

Trigger Boards

For the frame grabbers, the trigger boards control synchronous image and signal processing.
