acA640-90uc - Basler ace

The Basler acA640-90uc USB 3.0 camera with the Sony ICX424 CCD sensor delivers 90 frames per second at VGA resolution.

USB3 Vision
Add to request cart
Request test camera
Add to watch list
  • Basler ace - acA640-90uc
  • Basler ace - acA640-90uc
  • Basler ace - acA640-90uc
  • Basler ace - acA640-90uc
  • Basler ace - acA640-90uc
  • Basler ace - acA640-90uc

General Information
Order Number 106222
Product Line ace classic

Sensor
Sensor Vendor Sony
Sensor ICX424
Shutter Global Shutter
Max. Image Circle 1/3"
Sensor Type CCD
Sensor Size 4.9 mm x 3.7 mm
Resolution (H x V) 658 px x 492 px
Resolution VGA
Pixel Size (H x V) 7.4 µm x 7.4 µm
Frame Rate 90 fps
Mono/Color Color

EMVA Data
EMVA Quantum Efficiency - blue (typical) 1.3 %
EMVA Quantum Efficiency - green (typical) 34.2 %
EMVA Quantum Efficiency - red (typical) 1.4 %
Dark Noise (typical) 13.0 e¯
Saturation Capacity (typical) 14.9 ke¯
Dynamic Range (typical) 61.2 dB
Signal-to-Noise Ratio (typical) 41.7 dB

Camera Data
Interface USB 3.0
Pixel Bit Depth 12 bits
Synchronization
  • hardware trigger
  • free-run
  • software trigger
Exposure Control
  • programmable via the camera API
  • hardware trigger
Digital Input 1
Digital Output 1
General Purpose I/O 2
Power Requirements
  • Via USB 3.0 interface
Power Consumption (typical) 2.7 W

Housing
Housing Type Box
Housing Size (L x W x H) 29.3 mm x 29 mm x 29 mm
Lens Mount
  • C-mount
  • CS-mount
Housing Temperature 0 - 50°C
Weight (typical) 80g

Conformity
Conformity
  • CE
  • RoHS
  • GenICam
  • IP30
  • UL
  • FCC
  • USB3 Vision

Features
Chunks
  • CRC Checksum
  • Counter Value
  • Exposure Time
  • Gain
  • Line Status All
  • Sequencer Set Active
  • Timestamp
Color Creation and Enhancement
  • Balance White (Manual White Balance)
  • Balance White Auto (Automatic White Balance)
  • Color Adjustment (6-axis Hue/Saturation)
  • Light Source Presets
Event Reporting
  • Exposure End
  • Frame Burst Start
  • Frame Burst Start Overtrigger
  • Frame Burst Start Wait
  • Frame Start
  • Frame Start Overtrigger
  • Frame Start Wait
Image Acquisition Control
  • Acquisition Start Trigger
  • Acquisition Status
  • Frame Burst Start Trigger
  • Frame Start Trigger
  • Trigger Delay
  • Triggered by Hardware
  • Triggered by Software
Miscellaneous
  • Device Information Parameters
  • Remove Parameter Limits
  • User Defined Values
  • User Sets (Configuration Sets)
Physical Interface and I/O Control
  • Debouncer
  • I/O Signals: Frame Burst Start Wait
  • I/O Signals: Frame Start Wait
  • I/O Signals: Timer 1 Active
  • I/O Signals: User Output
  • Minimum Output Pulse Width
Pixel Formats
  • BGR 8
  • BGRA 8
  • Bayer 12
  • Bayer 8
  • Mono 8
  • RGB 8
Standard Features
  • Auto Function Profile
  • Black Level
  • Digital Shift
  • Exposure Auto
  • Exposure Mode: Timed (Control via API)
  • Exposure Mode: Trigger Width (Control via External Trigger)
  • Gain
  • Gain Auto
  • Gamma Correction
  • Lookup Table (LUT)
  • Region of Interest (ROI)
  • Reverse X (Horizontal Mirroring)
  • Test Images
Lenses

Lenses

On all cameras from the ace camera series featuring sensors of 1/2'' or smaller, you'll benefit from a perfect harmonization of camera and Basler Lenses. For ace cameras with larger sensors, you'll find lenses from certified and reliable manufacturers. These lenses have been tested extensively for compatibility with our ace cameras. You'll also find matching lens accessories here.
