Basler ace 2 a2A5328-35cm

IMX540 Sensor
35 fps Frame rate
CoaXPress (CXP-12) Interface
24.4 MP Resolution (MP)
1.2" Sensor Format

The Basler a2A5328-35cm CXP camera with the Sony IMX540 CMOS sensor delivers 35 frames per second at 24.4 MP resolution.

Select your model

Select Mono/Color:

Recommended accessories

Lens

Data Cable

Please select

Cable CXP, Micro-BNC x2 (HD BNC), P, 10 m +€109.00

Cable CXP, Micro-BNC x2 (HD-BNC), DrC,5m +€116.00

Cable CXP, Micro-BNC x2 (HD BNC), P, 5 m +€79.00

Cable CXP, Micro-BNC x2 (HD BNC), P, 3 m +€69.00

I/O Cables

Please select

Power-I/O Cable, M8 6p/open, P, 5 m +€29.20

Frame grabber/PC Cards

Please select

CXP-12 Interface Card 1C +€969.00

imaWorx CXP-12 Quad +€1,639.00

CXP-12 Interface Card 2C +€1,079.00

CXP-12 Interface Card 4C +€1,569.00

microEnable 5 marathon ACX-SP +€929.00

Cooling & Mounting

Please select

Heat sink for ace 2 and racer 2 S +€9.00

Tripod Mount racer 2 S and ace 2 +€15.00

Compressed Air Cooler ace 2 / racer 2 S +€69.00

Tripod Mount ace 2 and racer 2 S +€15.00

Quantity

Show suitable products

Suitable Products

Recommended software

pylon vTools for image processing
Design robust image processing software for quality assurance and tracking. Functions such as blob analysis, matching, and code reader can be combined using drag-and-drop design and flexibly integrated into the target application.
pylon Software for image acquisition
pylon offers certified drivers for many camera interfaces, as well as simple programming interfaces and practical tools for camera setup.

All Basler ace 2 Models

Haven't found the right model? See the product list for an overview of all ace 2 models. Find the right product for your application: filter by sensor, resolution, frame rate, and more.

To the ace 2 product table

Net list price	€2,879.00
Ready for dispatch	Standardapprox. 2 weeks

Manufacturer	Basler
Order Number	109264
Product Family	ace 2 V
Camera Series	Basler ace 2
Camera Category	Area Scan Camera
Warranty	36 Months

Sensor Vendor	Sony
Sensor	IMX540
Shutter	Global Shutter
Sensor Format	1.2"
Sensor Diagonal	19.26 mm
Sensor Type	CMOS
Sensor Size	14.57 mm × 12.6 mm
Resolution (H x V)	5328 px × 4608 px
Resolution	24.4 MP
Pixel Size (H x V)	2.74 μm × 2.74 μm
Frame rate	35 fpsCalculate individual frame rate
Mono/Color	Mono
Spectrum	Visible

Quantum Efficiency (typical/minimal)	67.3 % (typical)
Dark Noise (typical/maximal)	2.1 e¯ (typical)
Saturation Capacity (typical/minimal)	9.6 ke¯ (typical)
Dynamic Range (typical/minimal)	71 dB (typical)
Signal-to-Noise Ratio (typical/minimal)	39.9 dB (typical)

Interface	CoaXPress (CXP-12)
Image Data Interface	CoaXPress (2.5–12.5 Gbps)
Pixel Bit Depth	8 bits 10 bits 12 bits
Synchronization	free-run hardware trigger software trigger
Exposure Control	hardware trigger programmable via the camera API
Digital Input	1
General Purpose I/O	2
Power Supply	PoCXP
Power Requirements (typical)	3.7 W

Basler ace 2 a2A5328-35cm

Select Mono/Color:

General Information

Sensor

EMVA Data

Camera Data

Housing

Technical Drawing

Manufacturer

Conformity

Documentation

Features & Documentation

Easy Handling

Image Quality Optimization

Process Control

Speed Increase

Suitable Products

Recommended software

pylon vTools for image processing

pylon Software for image acquisition

All Basler ace 2 Models

Housing Type	Box
Protection Class	IP30
Housing Size (L x W x H)	29 mm x 29 mm
Weight	76 g
Lens Mount	C-mount
Operating Temperature	-10 °C - 50 °C

Auto Functions	Use the camera's auto functions to allow the camera to find the optimum settings for exposure time, gain, and white balance, for example. This simplifies camera integration into your application.
Presettings	Automate recurring steps in your application by using the camera's default settings and/or creating and saving your own presets.

Image Adjustment	Adjust pixel values losslessly with Black Level, Digital Shift, and other standard features.
Pixel Correction Beyond - Patented	Use the Dynamic Defect Pixel Correction to minimize the influence of disturbing defect pixels without affecting the structures in the image.

Burst Mode	Acquire a sequence of images after triggering once and output them as required. In High-Speed Burst Mode, you can temporarily bypass the data limitation of GigE.
Digital I/Os	Control the camera via trigger commands or use the camera to control components of your vision system, such as lighting or encoders.
Information Utilisation	Use additional information from Chunks and Events to optimize your automation.
Intelligent Light Control (SLP)	Control the lighting directly with the camera. By synchronizing the flash mode and adjusting the brightness levels, you can quickly achieve precise lighting conditions and shorten the development time of your application.
Sequencer	Program sequential processes in the camera to control image acquisition and pre-processing in real time.
Timing	Control the start and end of an exposure individually. Add delays or synchronize multiple cameras in a GigE network using PTP.
