Basler ace

Sensor: CMV4000
Resolution (MP): 4 MP
Sensor Format: 1"

Choose the right acA2040 (CMV4000) model for your needs.

Recommended software

pylon vTools for image processing
Design robust image processing software for quality assurance and tracking. Functions such as blob analysis, matching, and code reader can be combined using drag-and-drop design and flexibly integrated into the target application.
pylon Software for image acquisition
pylon offers certified drivers for many camera interfaces, as well as simple programming interfaces and practical tools for camera setup.

All Basler ace Models

Haven't found the right model? See the product list for an overview of all ace models. Find the right product for your application: filter by sensor, resolution, frame rate, and more.

To the ace product table

Manufacturer	Basler
Order Number	basler_ace_cmv4000
Camera Series	Basler ace
Camera Category	Area Scan Camera
Warranty	36 Months

Sensor Vendor	ams
Sensor	CMV4000
Shutter	Global Shutter
Sensor Format	1"
Sensor Diagonal	15.92 mm
Sensor Type	CMOS
Sensor Size	11.26 mm × 11.26 mm
Resolution (H x V)	2048 px × 2048 px
Resolution	4 MP
Pixel Size (H x V)	5.5 μm × 5.5 μm
Spectrum	Visible

Pixel Bit Depth	10 bits 12 bits
Exposure Control	hardware trigger programmable via the camera API
Digital Input	1

Housing Type	Box
Lens Mount	C-mount
